Velocity Microwave Legacy SMA-P Pin Gage

$649.00

Velocity Microwave

Velocity Microwave offers a revolutionary, new gage family! The patented design allows both male and female connectors to be measured with a single gage saving both time and money.

Velocity Microwave Gage Family
• One gage/one bushing for male and female connectors
• Type N gages (all series) only need a single master gage.
• Modular Design: Reduces calibration expense.

LEGACY Series
• Classic analog dial face
• Custom rear metal plate with compliance data for relevant standards
• Packaged in crush, water and dust-proof case
• Accuracies from +/- .00025 to +/- .0005
• A2LA compliant calibration certificate on a thumb-drive

9 in stock

SKU: VMLegacy-SMA-P Category: Tag:
Contact us today with your questions or to request a quote on this item.




Additional Information:

[Jump to Full Description]

Brand:

Description

The Legacy series of microwave connector gages is built around the classic ASME B89.1.10M dial interface on
top of a long standing and rock solid Mitutoyo indicator featuring a massive bridge for bearing support, hardened
stainless steel gears and pinions for long trouble free life, hardened stainless steel stem, non-glare stain case
finish, and positive grip bezel with unbreakable crystal and white non-reflecting eggshell finish.

The Legacy series features a single bushing/rack patent pending design for the measurement of both genders –
and in the case of Type N connectors for the measurement of all Standards – to simplify gaging. The series further
features a custom metal plate with permanently inscribed compliance data related to IEEE287LPC and GPC,
MIL-C-39012, and MIL-STD-348 as a further aid in compliance evaluation. Accuracies range from +/- 0.0005
to +/- 0.00025 and an A2LA accredited cal certification is included on a USB pen drive.

All Legacy gages are housed in a crush, water and dust proof NK-7 resin case featuring all stainless hardware, an
automatic pressure release valve, a Powerclaw latching system with soft grip handle and die cut interior with
accessories. The case is carry on compliant. Both case and gage are serialized.

Accessories

Options

Additional information

Weight 5 lbs
Dimensions 15 × 12 × 9 in
Condition

Model Number

Legacy SMA-P Pin Gage

Data Sheet

https://4gte.com/index.php/filemanager/datasheet/download/id/563/

Manual

Gage Instructional Manual https://4gte.com/index.php/filemanager/datasheet/download/id/547/

Manufacturer

Velocity Microwave
