Keysight M8190A-002/02G/12G/14B/BU2/DUC 12 GSa/s Waveform Generator
Keysight’s M8190A – A Keysight AWG is the source of greater fidelity, delivering high resolution and wide bandwidth – simultaneously.
Precision AWG with two DAC settings
- 14-bit resolution up to 8 GSa/s
- 12-bit resolution up to 12 GSa/s
High-speed arbitrary waveform generators
- Variable sample rate from 125 MSa/s to 8 / 12 GSa/s
- Spurious-free-dynamic range (SFDR) up to 90 dBc typical
- Up to 2 GSa arbitrary waveform memory per channel with advanced sequencing
Unique Performance – Unique Value
- Up to 90 dBc SFDR– Tones clearly stand out of noise (Even with thousands of tones)
- 2 GSa memory per channel– Realistic signal scenarios with long play time
- 5 GHz analog bandwidth– Mimic analog imperfections with custom ISI
Key applications
- Radar, Satellite, Electronic Warfare, Multilevel Signals
- ADC testing (Analog Digital Converter testing), Jitter Margin Testing
- Digital Video, Noise Power Ratio Measurement, Wireless HD, HDMI, MHL
- IEEE 802.11ad, CaTV, OFDM, Software Defined Radio
