Velocity Microwave Legacy 1.85-2.4 Gage

DISCONTINUED: See the Velocity Microwave Ergon 1.85mm/2.4mm Gage for replacement

Velocity Microwave offers a revolutionary, new gage family! The patented design allows both male and female connectors to be measured with a single gage saving both time and money.

Velocity Microwave Gage Family
• One gage/one bushing for male and female connectors
• Type N gages (all series) only need a single master gage.
• Modular Design: Reduces calibration expense.

LEGACY Series
• Classic analog dial face
• Custom rear metal plate with compliance data for relevant standards
• Packaged in crush, water and dust-proof case
• Accuracies from +/- .00025 to +/- .0005
• A2LA compliant calibration certificate on a thumb-drive

Please give us to call at 866-409-0400 to discuss when you can expect this product back in stock.

Description

The Legacy series of microwave connector gages is built around the classic ASME B89.1.10M dial interface on
top of a long standing and rock solid Mitutoyo indicator featuring a massive bridge for bearing support, hardened
stainless steel gears and pinions for long trouble free life, hardened stainless steel stem, non-glare stain case
finish, and positive grip bezel with unbreakable crystal and white non-reflecting eggshell finish.

The Legacy series features a single bushing/rack patent pending design for the measurement of both genders –
and in the case of Type N connectors for the measurement of all Standards – to simplify gaging. The series further
features a custom metal plate with permanently inscribed compliance data related to IEEE287LPC and GPC,
MIL-C-39012, and MIL-STD-348 as a further aid in compliance evaluation. Accuracies range from +/- 0.0005
to +/- 0.00025 and an A2LA accredited cal certification is included on a USB pen drive.

All Legacy gages are housed in a crush, water and dust proof NK-7 resin case featuring all stainless hardware, an
automatic pressure release valve, a Powerclaw latching system with soft grip handle and die cut interior with
accessories. The case is carry on compliant. Both case and gage are serialized.



Additional information

Weight 5 lbs
Dimensions 15 × 12 × 9 in
Condition

Model Number

Legacy 1.85-2.4 Gage

Data Sheet

https://4gte.com/index.php/filemanager/datasheet/download/id/559/

Manual

Gage Instructional Manual https://4gte.com/index.php/filemanager/datasheet/download/id/547/

Manufacturer

Velocity Microwave

Type
