Tektronix DPO7254 Digital Oscilloscope, 4-Channel, 2.5 GHz with Options DDRA/DJA


General Inquiries/Quote Request
Rental/Lease Information Request

Already Own One?
Get Repairs Calibration ...and more!

The Tektronix DPO7254 is part of Tektronix’s new generation of real-time digital phosphor oscilloscopes and are the industry’s best solution to the challenging signal integrity issues faced by designers verifying, characterizing, debugging and testing sophisticated electronic designs.

Unit includes:

DDRA – DDR Memory Technology Analysis Package

DJA  –    Jitter and Eye-Diagram Analysis – Advanced

SKU: TEKDPO7254-DDRA/DJA Categories: , , Tag:
Brand:

Description

    • Real-Time Sample Rates

    • 1 Channel (max): 40 GS/s
    • 2-Channel (max): 20 GS/s
    • 3-4 Channels (max): 10 GS/s

Standard Record Length

  • 1 Channel: 400 M
  • 2-Channel: 200 M
  • 3-4 Channels: 100 M

Accessories

Part Number Description
Qty
Power Cord
1
071-1733-00 Quick Start User Guide
1
071-1740-00 Service Guide
1
200-4963-00 Hard Plastic Instrument Cover
1
119-7054-00 Optical Mouse
1
016-1966-00 Accessory Pouch
1
067-0405-00 Probe Calibration and Deskew Fixture
1

Options

Option Description
10RL 400 MSamples max, 100 MSamples per Channel
2RL 80 MSamples max, 20 MSamples per Channel
5RL 200 MSamples max, 50 MSamples per Channel
ASM Advanced Event Search and Mark
DDRA DDR Memory Technology Analysis Package
DJA Jitter and Eye-diagram Analysis – Advanced
DJE Jitter and Eye-diagram Analysis – Essentials
LSA Low Speed Serial Analysis, CAN/LIN Trigger, Decode and Analysis
MTM Mask testing for Serial Communication Standards
JE3 TDSJIT3 Essentials Jitter Analysis Software
ET3 TDSET3 Ethernet Compliance Test Software (requires Ethernet Test Fixture)
PTM SERIAL PROTOCOL TRIGGER AND DECODE FOR DPO7000
PWR DPOPWR Power Measurement and Analysis Software
RTE RT-EYE (TM) SERIAL DATA COMPLIANCE ANALYSIS PACKAGE
SVE SIGNALVU ESSENTIALS – VECTOR SIGNAL ANALYSIS SOFTWARE
SVM SIGNALVU GENERAL PURPOSE MODULATION ANALYSIS. REQUIRES OPTION SVE
SVP SIGNALVU PULSE – ADVANCE SIGNAL ANALYSIS (INCLUDING PULSE MEASUREMENTS).
REQUIRES OPTION SVE
USB USB 2.0 Compliance Test Software
UWB Ultra Wideband analysis software option
UWBE Ultra-Wideband Essentials Ver 2.2

Additional information

Weight 36 lbs
Dimensions 18 × 13 × 12 in
Channels

4

Condition

Model Number

DPO7254

Frequency Low Khz

2500000

Low Frequency

2500000

Manufacturer

Tektronix

Sample Rate

40 Gs/s

Type

Content missing
