HP/Agilent Keysight E4438C – 003/005/506/602/UN7/UNB/UNJ ESG Vector Signal Generator, 250 kHz to 6 GHz



003 Digital Output Connectivity w/N5102A
005 6 Gbyte Hard Drive
506  250 kHz to 6 GHz
602 Internal Baseband Generator (32 Msamples Memory) with Digital Bus Capability
UN7 Internal Bit Error Rate Analyzer
UNB High Power Output with Mechanical Attenuator
UNJ Enhanced Phase Noise Performance
SKU: KEYE4438C - 003/005/506/602/UN7/UNB/UNJ Categories: ,
Brand:

Description

HP/Agilent Keysight E4438C – 003/005/506/602/UN7/UNB/UNJ ESG Vector Signal Generator, 250 kHz to 6 GHz

Frequency range 250 kHz to 1, 2, 3, 4, or 6 GHz Output power up to +17 dBm RF modulation bandwidth up to 160 MHz Flexible FSK, MSK, PSK, QAM, custom I/Q, AM, FM, ØM, and pulse Step & list sweep frequency and power Internal baseband generator (80 MHz RF BW) Arbitrary I/Q waveform playback (up to 100 MSa/s) Up to 64MSa playback memory and 1 GSa storage Real-time I/Q symbol generation (up to 50 Msym/s) Generate 802.11 WLAN, W-CDMA, cdma2000, 1xEV, TD-SCDMA, GSM, EDGE, cdmaOne, multitone, and more Digital I/O, fading, and PC HDD waveform streaming with Baseband Studio Remote control over 10BaseT LAN and GPIB SCPI and IVI-COM drivers



Additional information

Weight 43 lbs
Dimensions 12 × 22 × 26 in
