HP/Agilent 8753D Network Analyzer, 30 kHz to 3 GHz with Options 002/006/010/1D5 includes Calibration


General Inquiries/Quote Request
Rental/Lease Information Request

$3,350.00

1 in stock

Unit includes Options 002,006,010 and 010.  Unit also includes Calibration.

The Agilent HP Keysight 8753D is a high performance vector network analyzer for laboratory or production measurements of transmission and reflection parameters. It integrates a synthesized RF source and two separate measurement channels, a built-in transmission/reflection test set and color display. The HP/Agilent 8753D provides 50-Ohm transmission/reflection measurements and displays magnitude, phase and group delay responses of active and passive RF networks.

SKU: KEY8753D/002/006/010/1D5 3410A07237 Categories: , Tag: Brands: , ,

Description

Agilent HP Keysight 8753D Network Analyzer, 30 kHz to 3 GHz with Options 002/006/010/1D5

Built-in S-parameter test set for complete forward and reverse measurements,
allowing you to completely characterize your component with a single connection.

  • Superb accuracy, with the most comprehensive calibration available
  • Optional time domain and swept harmonic measurements
  • Mixer testing with frequency offset capability
  • Optional step attenuator for extended source output power range
  • Pass/fail testing, interpolative error correction, test sequencing, and
    user-defined test frequencies to enhance productivity
  • Two independent display channels for simultaneous measurement of reflection
    and transmission characteristics

Accessories

Part Number Description
Qty
08753-90256 Programmers Guide
1
08753-90257 User’s Guide
1
08753-90258 Installations & Quick Start Guide
1
08753-90405 Service Guide
1
08753-90259 Quick Reference Guide
1
Power Cord
1

Options

Option Description
002 Add Harmonic Measurement Capability
006 6 GHz Frequency Range
010 Time Domain Analysis Capability
011 Delete S-Parameter Test Set
075 75-Ohm Input Impedance
0B0 Delete Manual Set
0BV Service Documentation, Component Level
0BW Service Documentation, Assembly Level
0BX Service Documentation, Assembly & Component Level
1CM Rackmount Kit (5062-3979)
1CP Rackmount Kit with Handles (5062-4073)
1D5 High Stability Frequency Reference

Additional information

Weight 64 lbs
Dimensions 9 × 17 × 22 in
Condition

Model Number

8753D

Manufacturer

HP/Agilent

Ports

2

Power

-110 dBm – +10 dBm

Type
