Keysight 6623A System Power Supply, 40 or 80 W, 3 outputs

Out of stock

Please give us to call at 866-409-0400 to discuss when you can expect this product back in stock.

The Agilent 6623A is a triple-output, GPIB system power supply that has low noise power supply outputs combined with a built in GPIB interface. Simple programming commands ease access to all features and capabilities. Dual ranging outputs provide greater flexibility in available voltage and current.

Description

  • GPIB programming of voltage and current
  • Measured voltage and current read-back over the GPIB
  • Two outputs can be connected in parallel or in series
  • Automatic selection of operating voltage and current range
  • Programmable over-voltage and over-current protection
  • Self-test occurs at power-on from an GPIB command
  • Electronic calibration via GPIB
  • 10 store-recall states
  • SCPI (Standard Comments for Programming Instruments)
  • VXI plug&play drivers

Accessories

Part Number Description
Qty
Power Cord
1
5957-6377 Operating Manual
1
5957-6379 Service Manual
1
0360-2310 Barrier Block Jumpers

6

06624-20007 Barrier Block Cover
3

Options

Option Description
0B0 Delete Manual Set
0B3 Service Manual
0L1 Standard Documentation Package
0L2 Additional Standard Documentation Package
100 87-106 vac operation, 50/60 Hz
120 104-127VAC operation, 50/60Hz
220 191-233VAC operation, 50/60Hz
240 209-250VAC operation, 50/60Hz
750 Relay control and discrete fault indicator/remote inhibit port
908 Rackmount Kit for one unit
909 Rackmount Kit with Handles
J03 Modifies two 80w outputs to 35v, 3a
S50 Modifies 6623A-750 to turn outputs off and returns to programmed values.

Additional information

Weight 52 lbs
Dimensions 12 × 22 × 26 in
Condition

Model Number

6623A

Data Sheet

https://4gte.com/index.php/filemanager/datasheet/download/id/21/

Input Power

100,120,220,230

Manual

HP/Agilent 6623A Data Sheet https://4gte.com/index.php/filemanager/datasheet/download/id/21/

Manufacturer

HP/Agilent

Type

Voltage

7,20,7,20,50,20

Watts

80
