Keysight 3577A Network Analyzer System 5Hz-200MHz with Color LCD display

The HP Agilent  Keysight  3577A, Network Analyzer, which measures impedance parameters in the 5Hz to 200MHz frequency range. The Agilent HP 3577A is fully programmable with the HP-IB bus.
Basic measurements provided include magnitude/phase, insertion loss, electrical length, gain compression, and group delay. With the HP 35677A/B S-parameter test set, this unit can also measure return loss, reflection coefficients, and impedance in 50 or 75 ohm systems.

SKU: KEY3577A - Color LCD Display Categories: , Tag: Brand: , ,

Description

High speed/high accuracy measurements
0.001 dB, .005 degree, 1 ps, .001 Hz resolution
Built-in three-term error correction plus normalization
Magnitude, phase, polar, real, imaginary, and group delay display modes
Convenience features including direct plotter control and vector math
functions

Keysight 3577A Network Analyzer System 5Hz-200MHz with Color LCD display

Additional information

Weight 62 lbs
Dimensions 9 × 17 × 24 in
