Description
Real-time Signal Processing:
Low Pass Filter: Stops from 10Hz to 10kHz
High Pass Filter: Starts from .1Hz to 100Hz
Notch Filter: 50 or 60Hz Center
RMS: Time constant selectable from .02 to 2 seconds
Frequency: Based on TEV, 5Hz to 10kHz
Cross Channel: Ratio, Product (Power), Sum, Difference,
Multiplication, Division, Phase
Recording:
Recording Method: Internal disk drive 36GB
Sample Rate: .1 samples/second to 100,000 samples/second each
channel (all channels)
Total Capacity: Over 16 billion samples
Time Stamp: Time and Date saved with data
Header: Information on units, range, sample rates, etc.
saved with dataannels)
Events: All captured with waveforms Outputs:
Auto Arm: Allows automatic stacking of captures
Auto Playback: Yes captured with waveforms Outputs:rates, etc.
General Specifications:
Number of Channels: 6 (per module)
Isolation: 250Vrms
Bandwidth: 12kHz (-3dB)
Input Coupling: DC
Single-ended Voltage:
Input Type: Isolated, single-ended
Max. Rated Input: +/-250Vrms
Specified Ranges: 40 to 400 vfs; 4 to 40 Vfs; .4 to 4 Vfs
Differential Voltage Measurements:
Input Type: Isolated, differential
Absolute Max Input: +/-40V differential
Measuring Ranges: 200 to 1600mVfs; 50 to 500mVfs; 5 to 50mVfs
Bridge Measurements:
Measuring Ranges: 200 to 1600mVfs; 50 to 500mVfs; 5 to 50mVfs
Thermocouple Measurements:
Specified Ranges: Type J: 0 to 760 degrees C
Type K: 0 to 1370 degrees C
Type T: -160 to 400 degrees C
Type E: -100 to 1000 degrees C
Type N: 0 to 1300 degrees C
Removable Drive:
Type: DVD+/-RW (4.7GB)
