Anritsu MG3697C Signal Generator 2 to 67/70 GHz with Options 2C/3/4/6/15D/28B

• Industry Best Broad Frequency Coverage
• Industry Best Phase Noise
• Industry Best Pulse Modulation
• Fast Switching Speed
• Full Analog Modulation
• High Output Power
• Highly Configurable
• Highly Reliable

SKU: ANRMG3697C-2C/3/4/6/15D/28B Category: Tag: Brand:

Description

Anritsu MG3697C Signal Generator 2 to 67/70 GHz with Options 2C/3/4/6/15D/28B

The MG3690C series of broadband signal generators covers audio, HF, VHF, UHF, RF and microwave frequencies from 0.1 Hz to 70 GHz in single coaxial output and up to 500 GHz or beyond, with external multipliers. In addition, it is easy to operate either through intuitive front panel controls or remotely via GPIB or Ethernet connectivity. Thus, the MG3690C series is an ideal signal source for both RF and microwave requirements, fully configurable for simple to high performance applications.
The MG3690C replaces the MG3690B signal generator, offering three levels of best-in-class SSB phase noise performance; Standard, Ultra Low Phase Noise (option 3) and Premium Phase Noise (option3X), along with full suite of modulation capabilities for signal simulations from simple to the most complex. For IQ modulation, the IF input option allows the easy up-conversion of an externally IQ-modulated RF signal

Additional information

Weight 42 lbs
Dimensions 12 × 22 × 26 in
