Tektronix TDS680C Digital Real-Time Oscilloscope -2 Channel w/Opts. 13, 1F,
2F
1 GHz Bandwidth
10 GS/s and 5 GS/s Sample Rates on all Channels Simultaneously for Full Bandwidth Single-shot Capture
Histograms and Measurement Statistics to More Fully Characterize Design Performance
Support for Java Applications
Tektronix P7380A 8GHz Z-Active Differential Probe with Accessories & Case
The Tektronix P7380A is an 8 GHz Z-Active Differential Probe. Tektronix’ active probe architecture preserves high bandwidth while providing improved connectivity with low loading. The Z-Active architecture is a hybrid approach composed of a distributed attenuator topology feeding an active probe amplifier. With Z-Active architecture, the P7380A uses a passive probe tip element that is separate from the amplifier, extending the usable reach of the probe. The P7380A architecture maintains high DC input resistance and a higher AC impedance than previous probe architectures while providing significant length between the probe body and the probe attachment point to the DUT. This architecture provides the best of both worlds, high DC impedance along with the stable high frequency loading of Z0 probes.
Read More
Tektronix P6717 General Purpose Logic Probe with Accessories
The P6717 general-purpose logic probe connects the Tektronix MSO70000 Series of mixed-signal oscilloscopes to digital buses and signals on your target system. The probe includes 16 data channels and one clock/data channel. Each probe channel includes a signal pin and a ground pin. You can connect the probe leads separately to the target system, or group the leads together using the probe tip holders
Read More
Tektronix MTS 300 MPEG Test System with Options*
*MPEG System Analyzer, MPEG2 Transport Multiplexer, DVB Table Editor and DVB Channel Coding/Decoding, Packet Jitter, MPEG Audio and Video Stream Analyzers, Program Stream AnalyzerTektronix MTS 300 MPEG Test System with Options*
Read More
The Tektronix FG503 is a 3 MHz function generator plug-in for the TM500 system.The FG503 has six decade frequency multiplier steps, a custom position for user-determined frequency multiplication, a dial calibrated from 1.0 to 30 (uncalibrated from 0.1 to 1.0),
The Frequency vernier control working together to select frequencies in overlapping ranges from 1 Hz to 3 MHz. The output frequency can be swept over a 1000:1 ratio by an external voltage..
Read More
This Plug-in is a used Frequency Counter Plug-In that is designed to operate in a TM 500 Series Power Module.
This unit has seven measurement functions, such as frequency counting, finding frequency ratios, period timing, interval timing, width timing, electronic event counting, and manual event counting.
This unit has two input channels (A&B), each have BNC inputs and separate triggering levels, attenuators, and coupling mode controls, and 225MHz capability.
Provides 7-digit LED display.
Read More
Tektronix ASG 140 Audio Signal Generator
ASG140 Applications
The ASG140 is designed for situations requiring no in-line connections. Its four audio outputs are grouped in two stereo pairs making it the ideal choice for service and alignment of MII, Betacam, D1, D2 and D3 VTRs. Its audio output features 10 Ohm output impedance
