Description
The 86100C DCA-J combines extremely high accuracy and precise repeatability with great ease of use to simplify characterizing signals from 50 MHz to 80GHz. Digital designers can combine the mainframe and modules into four key instruments with industry leading signal integrity performance, including:
A digital communications analyzer with automated eye diagram analysis for transmitter compliance testing
A full-function time domain reflectometer (TDR) for high precision S-parameter impedance analysis
A full-function oscilloscope with bandwidth in excess of 80 GHz, ensuring the most accurate waveform measurements
The industry’s most accurate jitter analyzer, measuring subcomponent jitter sources with one-button ease of useAccessories
| Part Number | Description |
Qty
|
| 0960-2427 | USB Keyboard |
1
|
| 1150-7799 | USB Mouse |
1
|
| Power Cord |
1
|
|
| 5061-5311 | APC 3.5mm (f-f) adapter/connector saver |
1
|
| 86100-90064 | Quick Start Guide |
1
|
| 86100-90065 | Programmer’s Guide |
1
|
| 86100-90066 | Installation Guide for Plug-ins |
1
|
| 5962-5965 | Connector Reference Manual |
1
|
| 86100-90064 | Programmer’s Guide Supplement |
1
|
| 86100-90075 | Service Manual |
1
|
Options
| Option | Description |
| 001 | 13 GHz Trigger Bandwidth |
| 090 | Removable Hard Drive |
| 100 | Jitter Analysis Software |
| 200 | Enhanced Jitter Analysis Software |
| 201 | Advanced Waveform Analysis Software |
| AX4 | Rack Flange Kit |
| AXE | Rackmount Kit with Handles |
