Description
Troubleshoot low voltage logic circuitry
Analog circuit analysis allows in-circuit testing
Test passive devices without removing them from the circuit
Test gate-fired devices
Perfect for benchtop or field repairs
Source parameters clearly defined on the front panel overlay
Voltage
Resistance
Test Frequency
100 combinations of voltage, source resistance and test frequency
DC stimulus variable -5 to +5 volts
Switch gate fired devices such as SCRs and optical couplers
Test gate fired devices in the open and closed states
2 Channels
2.8 in.Diagonal Mono Display
25 Selectable Voltage/Resistance ranges
Frequencies: 20Hz, 50/60Hz, 200Hz, 2kHz
Waveform: Sine Wave
Range Selection: Manual or Auto
Automatic circuit breaker
