Keysight 8565EC Portable Spectrum Analyzer, 9 kHz to 50 GHz

Out of stock

Quote Request

Please give us to call at 866-409-0400 to discuss when you can expect this product back in stock.

Already own one?

The Agilent 8565EC portable, color display millimeter wave spectrum analyzer offers the measurement capability and performance previously found in larger, more expensive benchtop analyzers. You can measure signals from 30 Hz to 40 GHz (preselected above 2.75 GHz) with a single coaxial connection.
The 8565EC combines outstanding phase noise, sensitivity, 1 Hz resolution bandwidths, synthesized tuning and wide dynamic range in a package built to withstand environmental conditions. It offers a complete solution for adjacent-channel power (ACP) testing of burst carrier signals using digital modulation, and the ability to measure occupied bandwidth percentage.

Description

Outstanding performance for sensitivity, phase noise, the 2nd and 3rd
order dynamic range, and the voltage standing wave ratio (VSWR)
Color Display
Continuous 30 Hz to 50 GHz sweep
Fast digital resolution bandwidths of 1, 3, 10, 30 and 100 Hz
Adjacent channel power, channel power, carrier power, occupied bandwidth
percentage and time-gated measurements standard
Precision timebase and 1 Hz counter resolution
MIL-PRF-28800 Class 3 rugged
Measurement personalities for digital radio and phase noise measurements
Easily transfer screen image or trace data to PC

Additional information

Weight 26 lbs
Dimensions 12 × 22 × 26 in
