Description
- DC to 50 GHz frequency range
- Calibration standards to perform full two-port calibration
- Torque wrenches for properly connecting standards
- Adapters to change the sex of the test port
- Standard definitions on disk for loading into network analyzer
Accessories
Part Number | Description |
Qty
|
85056-90020 | User and Service Guide |
1
|
85056-60022 | Male Offset Open |
1
|
85056-60023 | Female Offset Open |
1
|
85056-60021 | Female Offest Short |
1
|
85056-60020 | Male Offest Short |
1
|
00901-60003 | Male Broadband Load |
1
|
00901-60004 | Female Broadband Load |
1
|
00915-60003 | Male Sliding Load |
1
|
00915-60004 | Female Sliding Load |
1
|
85056-60006 | 2.4mm (f-f) adapter |
1
|
85056-60005 | 2.4mm (m-m) adapter |
1
|
85056-60007 | 2.4mm (m-f) adapter |
1
|
11752-60108 | Male Gage Kit (includes gage master) |
1
|
11752-60107 | Female Gage Kit (includes gage master) |
1
|
85056-20001 | Centering Bead (for gaging 2.4mm sliding loads) |
1
|
8710-1765 | 5/16 in, 8 in-lb Torque Wrench |
1
|
8710-1761 | 7mm Open-End Wrench |
1
|
85056-10003 | Calibration Definitions Disk (8510 and 872x) |
1
|
85056-10009 | Calibration Definitions Disk (PNA Series) |
1
|
08510-10033 | Specifications and Performance Verification Disk |
1
|
Options
