The Agilent 1671G offers solid logic analyzer performance.

Deep memory options let you capture more data and save you from having to set up complex triggers. The integrated oscilloscope option lets you view analog and digital signals simultaneously. The integrated pattern generator option lets you stimulate a device under test while you capture its response with the logic analyzer.

SKU: KEY1671G Categories: , Tag:
Brand:

Description

  • 102 channels of logic analysis
  • Solid performance: 150 MHz state speed, 500 MHz timing speed, 64K standard
    acquisition memory, 256K memory with Option 001, 2M memory with Option 002
  • Option 003 Oscilloscope: 2 channel, 500 MHz, 2 GSa/s, 32K memory
  • Option 004 Pattern Generator: 32 channel, 100M vector/sec, 256K vector deep
  • 2 GB hard drive and 1.44 MB DOS floppy drive
  • VGA resolution, color, flat-panel display helps you to find information quickly
  • Navigating through the well-designed user interface is made simple via
    your choice of either mouse or front-panel operation
  • Optional PC-style keyboard supported
  • File formats for ASCII data and PCX/TIFF/EPS screen shots
  • Centronics printer port, GPIB and RS-232 programmability
  • LAN for remote operation via X-Windows and data transfers via FTP/NFS
  • 23 predefined trigger functions with graphical representations and plain
    language descriptions for easy setup of powerful measurements

Accessories

Part Number Description
Qty
Power Cord
1
01650-61608 16-channel probe lead set
6
01670-94307 Logic Analyzer probe labels
1
5090-4833 SMD IC clips (pkg of 20)
6
5959-9334 Short Ground Leads (pkg of 5)
1
01660-61605 Probe Cables
3
5090-4356 Grabbers (20 per pk)
6
16542-61607 Double Probe Adapter
1
C3751-60201 PS2 Mouse
1
01670-97023 1670G-Series Service Guide
1
01670-97022 1670G-Series User’s Guide
1
01670-97021 1670G-Series Programmer’s Guide
1
E2433-97038 Training Kit Manual for 1670G-Series
1
E2433-60013 Logic Analyzer Training Kit
1
01660-99016 Accessories Pouch
1
01650-63202 RS-232-C loopback Connector
1
1160A 10:1 Probes (O-scope option only)
2
1250-1154 BNC miniprobe adapter (o-scope option only)
1

Options

Option Description
013 Tri-State TTL/CMOS Data Pod and Lead Set
014 TTL Data Pod and Lead Set
015 2.5 volt Clock Pod and Lead Set
016 Tri-State 2.5 volt Data Pod and Lead Set
017 3.3 volt Clock Pod and Lead Set
018 3.3 volt TTL Tri-State Data Pod and Lead Set
021 ECL Clock Pod and Lead Set
022 ECL (Terminated) Data Pod and Lead Set
023 ECL (Unterminated ) Data Pod and Lead Set
031 5 volt PECL Clock Pod and Lead Set
032 5 volt PECL Data Pod and Lead Set
033 3.3 volt LVPECL Clock Pod and Lead Set
034 3.3 volt LVPECL Data Pod and Lead Set
042 1.8 volt 3-State Data Pod and Lead Set
051 LVDS Clock Pod and Lead Set
052 LVDS Data Pod and Lead Set
0B1 Additional User’s Guide
0B3 Service Manual
0BF Programming Reference Manual
1CM Rackmount Kit

Additional information

Weight 24 lbs
Dimensions 22 × 15 × 12 in
Channels

102

Clock Rate

150 MHz

Condition

Model Number

1671G

Manual

HP/Agilent 1671G Programmers Guide https://4gte.com/index.php/filemanager/datasheet/download/id/179/

Manufacturer

HP/Agilent

Timing

500 MHz

Type

Content missing
