This kit includes option 2MF – K (male) to K (female)
The 36585 Series Precision AutoCal provides the highest performance calibration, barring the use of multiple airlines for an LRL coaxial calibration. The latter is used only by metrology centers due to its tedious nature, requiring the manual insertion of center conductors and outer shells of multiple beadless air lines. However, because the AutoCal calibration method is a transfer method that is based on the LRL Calibration, it provides better corrected characteristics than any SOLT manual calibration, even if using a Sliding Load. Coupled with the fact that automatic calibrations are much faster and less error-prone than manual calibrations, the precision AutoCal becomes the preferred VNA calibration method for all applications, from R&D to Manufacturing.
The HP/Agilent 4286A RF LCR Meter offers accurate and reliable measurements. The HP 4286A employs a RF I-V measurement technique, as opposed to the reflection measurement technique, yielding an accurate impedance measurement that extends way beyond 50 Ohms.
The 4286A provides you with an accurate impedance measurement capability for RF inductors, especially for nH values. Q measurement accuracy has been improved due to HP’s advanced calibration technique; typical Q accuracy is 6% @ 100 MHz (Q=100). You can reduce the design uncertainty by measuring your devices true impedance values at operating conditions.
Read More
The 80C05 module is optimized for testing long-wavelength (1520 to 1580 nm) telecom signals at 40 Gbps and with reference receiver filtering provided for9.953 Gbps. The 80C05, with its selectable bandwidth, lets the user choose optimal noise vs. bandwidth performance to accurately characterize the signal. With its high optical bandwidth (40 GHz), it is also well-suited for general purpose, high performance optical component testing.
Read More
The MSO4000 Series Mixed Signal Oscilloscopes (MSOs) provide all the features and benefits of the DPO4000, but add 16 integrated digital channels, enabling you to visualize and correlate analog and digital signals on a single instrument. This integration extends triggering functionality across all 20 channels providing pattern and state triggering ideal for debugging mixed analog and digital designs.
Read More
The Anritsu Calibration kits contain all the precision components and tools required to calibrate your VNA or VNMS for 12-term error-corrected measurements in the connector style of your choice. Components are included for calibrating male and female test ports as required. The kits support calibration with opens, shorts, and broadband loads. Option 1 adds sliding terminations and a pin depth gauge where required.
Short, Flush (2)
Offsets, 1/8 and 3/8 Wavelength
Terminations, Fixed (2)
Test Port Sections (2)
Includes Fresh Calibration.
The Agilent 83752A sweeper brings outstanding synthesized performance to the component-test marketplace. It delivers the best performance for the price in general purpose benchtop, swept test or scalar applications. This sweeper provides superior accuracy and stability while maintaining the speed of an analog source. Fully synthesized CW, stepped and ramp sweep modes are available in broadband and narrowband operation. The synthesis capability is particularly useful for the characterization of narrowband devices, in which the frequency instabilities of open-loop sources become most apparent. Excellent output power flatness and accuracy can be translated to the input port of the device under test with the power flatness correction feature of this source.
Agilent HP Keysight 83752A Synthesized Sweeper, 0.01 – 20 GHz
Read More
This unit includes two 81112A output modules.
Unit come calibrated, if current calibration date is less than 6 months until expiration, unit will be re-calibrated prior to shipping.
The Agilent 81110A is a 330 MHz single-/dual-channel Pulse Pattern Generator.
The alternative 81112A Output modules allow the 81110A to be used in applications up to 330 MHz. Instead of variable transitions, 800 ps or 1.6 ns edges can be selected. The source impedance is 50-ohm and supplies up to 3.8 Vpp into 50 ohms. Internal channel addition is not implemented.
NOTE:
Each Agilent 81110A 165/330 MHz single- or dual-channel Pulse Pattern Generator requires 1 or 2 of the following output channels:
– Agilent 81111A 165 MHz, 10 V, 50 Ohm into 50 Ohm
– Agilent 81112A 330 MHz, 3.8 V, 50 Ohm into 50 Ohm
Note: Only add together output modules of the same module number. A combination of the Agilent 81111A and Agilent 81112A in one Agilent 81110A is not possible.
