The HP/Agilent N4416A S-parameter test set is a key component of an Agilent physical layer and balanced-measurement system. When combined with an Agilent PNA Series E8356A, E8357A, or E8358A. Option 015 vector network analyzer and an external PC equipped with an IEEE-488 GPIB card, this test set makes characterizing high-speed digital interconnects as well as, fully balanced or balanced-to-single-ended RF components a lot easier.
The N4416A S-parameter test set requires the N4425A Balanced Measurement System software or the N1930A Physical Layer Test System software for control of the 4-port VNA system, calibration, and data display and analysis.
Read More
- Frequency range from 15 MHz – 3.35 GHz
- Two output channels
- Low jitter
- Fast rise times (20%-80%) < 60 ps
- Delay modulation (jitter emulation)
- Variable cross-over point (eye deformation) LVDS applications can be addressed with output levels from 50 mV to 2 V Pre-/de-emphasis and squelch levels for PCI Express and serial ATA
- LVDS applications can be addressed with output levels from 50 mV to 2 V
- Pre-/de-emphasis and squelch levels for PCI Express and serial ATA
